Source Coding

Source Coding Theorem (Shannon's First Theorem)

For a discrete memoryless source (DMS) with entropy $H(X)$, the expected codeword length $L$ of any uniquely decodable code satisfies:

$H(X) \leq L < H(X) + 1$

More generally, for block coding of $n$ i.i.d. symbols, there exists a code with rate approaching $H(X)$ bits/symbol as $n \to \infty$. No lossless code can achieve rate below $H(X)$.

Asymptotic equipartition property (AEP): for i.i.d. $X_1, \ldots, X_n$:

$-\frac{1}{n} \log p(X_1, \ldots, X_n) \xrightarrow{p} H(X)$

The typical set $A_\epsilon^{(n)} = \{x^n : 2^{-n(H+\epsilon)} \leq p(x^n) \leq 2^{-n(H-\epsilon)}\}$ has probability approaching 1, size approximately $2^{nH}$, and each element has roughly equal probability. This justifies encoding only typical sequences.

Kraft Inequality

For a $D$-ary prefix-free code with codeword lengths $\ell_1, \ldots, \ell_m$:

$\sum_{i=1}^{m} D^{-\ell_i} \leq 1$

Conversely, given lengths satisfying Kraft's inequality, a prefix-free code with those lengths exists. Extended to uniquely decodable codes by the McMillan inequality (same bound). The optimal codeword length for symbol $x_i$ is $\ell_i^* = -\log_D p(x_i)$, which is generally non-integer, motivating arithmetic coding.

Huffman Coding

Optimal prefix-free code for known symbol probabilities. Construction via greedy bottom-up tree building:

1. Create leaf node for each symbol with its probability
2. Repeatedly merge the two lowest-probability nodes into a parent
3. Assign 0/1 to left/right branches

Properties:

• Achieves $H(X) \leq L_{\text{Huffman}} < H(X) + 1$
• Optimal among all prefix-free codes for single-symbol coding
• Suboptimal when probabilities are far from powers of 2 (e.g., $p = 0.99$ yields 1 bit/symbol vs. $H \approx 0.08$)
• Adaptive Huffman (Vitter's algorithm): updates tree online without two-pass processing
• Canonical Huffman: standardized assignment enabling compact code description (used in DEFLATE)

Arithmetic Coding

Encodes an entire message as a single number in $[0, 1)$, approaching entropy optimally even for skewed distributions.

Encoding: maintain interval $[L, H)$, initially $[0, 1)$. For each symbol $s$ with CDF range $[c_s, c_s + p_s)$:

$L_{\text{new}} = L + (H - L) \cdot c_s, \quad H_{\text{new}} = L + (H - L) \cdot (c_s + p_s)$

Decoding: reverse the process, reading the fractional value and determining which symbol's interval contains it.

Practical considerations:

• Finite precision: use integer arithmetic with periodic renormalization (output leading bits when interval narrows sufficiently)
• Carry propagation: handle via bit-stuffing or range coder variant
• Achieves within 2 bits of optimal for any message length (vs. Huffman's 1 bit/symbol overhead)
• Used in JPEG 2000, H.264 (CABAC), and modern ML-based compressors

Range coding: variant that operates on bytes instead of bits, avoiding carry issues and simplifying implementation. Essentially equivalent compression ratio.

Asymmetric Numeral Systems (ANS)

A modern entropy coding family by Jarek Duda (2009) combining arithmetic coding's compression ratio with Huffman's speed.

Basic ANS: state $x$ encodes symbol $s$ via $C(x, s) = d_s + (\lfloor x/f_s \rfloor \cdot M + \text{cumul}_s)$ where $f_s$ is the quantized frequency and $M = \sum f_s$.

Two practical variants:

• tANS (tabled ANS): precomputed lookup tables, single table lookup per symbol, no multiplications. Extremely fast decoding
• rANS (ranged ANS): operates like a range coder but with a single state integer. Supports streaming with renormalization

Properties:

• Asymptotically optimal (approaches entropy)
• LIFO encoding order (encode in reverse, decode forward) unless interleaved
• Used in Zstandard (zstd), LZFSE (Apple), and JPEG XL

Lempel-Ziv Compression

Dictionary-based methods that achieve universality (no knowledge of source statistics needed).

LZ77 (Sliding Window)

Encode each position as $(d, \ell, c)$: distance back to match, length of match, next character. Uses a sliding window of recent history as the dictionary.

• Foundation of DEFLATE, gzip, zlib
• Parsing is greedy (longest match); optimal parsing is $O(n \log n)$
• Universal: achieves entropy rate for stationary ergodic sources

LZ78 (Dictionary Building)

Build dictionary incrementally: each new phrase is the longest previously seen phrase plus one new character. Dictionary entries are numbered sequentially.

• Simpler dictionary management than LZ77
• LZW variant: dictionary initialized with single-character strings; output dictionary index only (no extra character). Used in GIF, early Unix compress

Universality

Both LZ77 and LZ78 are universal compressors: for any stationary ergodic source, the compression ratio converges to $H(\mathcal{X})$. This is remarkable---no knowledge of the source distribution is needed.

Practical Compression Systems

| System | Algorithm | Typical Speed | Notes | |---|---|---|---| | gzip | DEFLATE (LZ77 + Huffman) | Moderate | Ubiquitous, RFC 1951 | | Brotli | LZ77 + context-dependent Huffman + static dictionary | Slower encode | Web standard, ~20% better than gzip | | Zstandard (zstd) | LZ77 + tANS + Huffman | Very fast | Facebook, dictionary training support | | LZMA/xz | LZ77 + range coding | Slow encode, fast decode | High ratio, 7-Zip | | lz4 | LZ77 (simple) | Extremely fast | Low ratio, real-time use | | Bzip2 | BWT + MTF + Huffman | Moderate | Good ratio, largely superseded |

Burrows-Wheeler Transform (BWT): reversible permutation that groups similar contexts together, making the output highly compressible by subsequent stages (move-to-front + entropy coding).

Rate-Distortion Theory

For lossy compression, Shannon's rate-distortion theory characterizes the minimum rate $R$ to represent a source within distortion $D$:

$R(D) = \min_{p(\hat{x}|x): \mathbb{E}[d(X,\hat{X})] \leq D} I(X; \hat{X})$

Key results:

• Gaussian source with MSE distortion: $R(D) = \frac{1}{2}\log\frac{\sigma^2}{D}$ for $0 \leq D \leq \sigma^2$
• Binary source with Hamming distortion: $R(D) = H_b(p) - H_b(D)$ for $0 \leq D \leq \min(p, 1-p)$
• $R(D)$ is convex, non-increasing in $D$
• Achieved by random codebooks of size $2^{nR}$ with joint typicality encoding

Blahut-Arimoto algorithm: iterative method to compute $R(D)$ (alternating minimization).

The distortion-rate function $D(R)$ is the inverse, giving minimum achievable distortion at rate $R$. In practice, practical codecs (JPEG, HEVC, AV1) operate above $R(D)$ but approach it with increasing block size and complexity.

Successive Refinement and Scalable Coding

A source is successively refinable if encoding at rate $R_1$ to distortion $D_1$, then sending additional rate $R_2$ to reach distortion $D_2$, achieves the same total rate $R_1 + R_2$ as encoding directly at $D_2$. Gaussian sources with MSE are successively refinable; binary sources with Hamming distortion generally are not.

Distributed Source Coding

Slepian-Wolf Theorem

For lossless distributed compression of correlated sources $(X, Y)$ encoded separately but decoded jointly, the achievable rate region is:

$R_X \geq H(X|Y), \quad R_Y \geq H(Y|X), \quad R_X + R_Y \geq H(X, Y)$

This is remarkable: separate encoding is as efficient as joint encoding. The corner points correspond to one encoder operating at full rate while the other exploits correlation.

Practical schemes: DISCUS (distributed source coding using syndromes), based on channel codes. Turbo/LDPC codes can approach Slepian-Wolf bounds.

Wyner-Ziv Theorem

Lossy analog of Slepian-Wolf: for encoding $X$ with side information $Y$ available only at the decoder, the rate-distortion function equals what it would be if $Y$ were available at the encoder too (for Gaussian sources with MSE, and in general for the quadratic-Gaussian case). For general sources, there can be a rate loss.

Quantization

Scalar quantization: partition the input range into intervals, map to representative points.

• Uniform quantizer: intervals of equal width. For high-rate regime, distortion $\approx \frac{\Delta^2}{12}$
• Lloyd-Max quantizer: iteratively optimizes partition boundaries and centroids to minimize MSE. Optimal for a given number of levels
• Companding: apply nonlinear transform before uniform quantization ($\mu$-law, A-law in telephony)

Vector quantization (VQ): quantize blocks of samples jointly. Achieves rate-distortion bound as dimension grows. LBG algorithm (generalized Lloyd) for codebook design. Computational cost is the main limitation, addressed by structured codebooks (lattice VQ, tree-structured VQ).

Transform Coding

Apply invertible transform, then quantize coefficients independently:

1. KLT (Karhunen-Loeve): optimal decorrelation, diagonalizes covariance. Data-dependent
2. DCT: approximates KLT for Markov sources. Foundation of JPEG, MPEG
3. Wavelets: multi-resolution analysis. Used in JPEG 2000

Reverse water-filling: optimal bit allocation across transform coefficients---allocate more bits to higher-variance components, zero bits to components below a threshold.

Practical Lossy Compression Pipeline

Modern codecs (H.265/HEVC, AV1, VVC) follow:

1. Prediction (intra/inter) to exploit spatial/temporal redundancy
2. Transform (DCT variants) of residual
3. Quantization (with rate-distortion optimization per block)
4. Entropy coding (CABAC/ANS) of quantized coefficients

Neural compression: learned nonlinear transforms + learned entropy models (hyperprior, autoregressive). Competitive with or superior to traditional codecs (e.g., Balle et al.'s framework, VTM-level performance at lower complexity in some regimes).
